A Practical Guide to NORYL Resin Grades and Applications

NORYL is a family of modified polyphenylene ether (PPE) resins. These blends of PPE and polystyrene deliver a strong balance of properties: affordable high heat resistance, excellent electrical insulation, hydrolytic stability, and compatibility with non-halogenated flame retardants, all within a low-density material.

The following sections break down the extensive NORYL portfolio into distinct categories based on their primary characteristics and target applications.

General Purpose and Automotive Grades (PX and N Series)

This category includes many of the workhorse grades, often unfilled and well-suited for automotive interior and exterior components.

• PX0844 & PX0888: Non-reinforced and injection moldable. Very low moisture absorption. Good foam adhesion. UL94 HB rated. Ideal for instrument panels and speaker housings.
• PX1112, PX1134, PX1180, PX1181: Impact modified for toughness. High heat resistance. Low specific gravity. Meets ECE Dashboard Impact Test. Suitable for body panels and interior parts.
• PX1185: Lubricated and impact modified. Works for automotive trim. Can be injection molded or profile extruded.
• PX1390 & PX138H: PX1390 is non-reinforced with high heat resistance. Ideal for automotive connectors. PX138H is 20% glass reinforced. Offers high strength and low warpage.
• N1050, N1150, N1250, N1250G: Non-brominated, non-chlorinated flame retardants. N1050 carries UL94 5VA at 2.5mm. N1250G is a bio-based version.
• N190, N1900, N190X: High impact strength. Very low moisture absorption. UL94 5VA at 3mm. Good for outdoor solar frames and UPS housings.
• N225X, N300X: Good dielectric strength. Works for indoor and outdoor electrical applications.

Glass Fiber Reinforced Grades (GFN Series)

These grades add glass fiber for stiffness and heat resistance.

• GFN1 & GFN1F: 10% glass fiber. High strength and low warpage. GFN1F meets food contact regulations.
• GFN2, GFN2F, GFN20, GFN20F, GFN2L: 20% glass fiber. Excellent dimensional stability. GFN20F carries UL746C F1 outdoor rating. Also FDA compliant.
• GFN3, GFN3F, GFN30, GFN30F: 30% glass fiber. Highest stiffness in the series. Very low moisture absorption. GFN30F is NSF 61 for potable water.
• GFN2BIO3: 20% glass fiber with bio-based content. UL746C F1 rating. Good for construction and lawn equipment.

High-Performance and Specialty Grades

These grades include specialized reinforcements for unique needs.

• PX1630 & PX1860: PX1630 is 30% glass for water management. Certified for potable water up to 85°C. PX1860 is unfilled and heat stabilized.
• PX2630 & PX2630F: High impact extrusion grades. PX2630F is FDA compliant. Very low moisture absorption.
• PX2935 & PX2938: 20% glass fiber reinforced. High impact and hydrolytic stability. PX2938 carries UL94 V0.
• PX500: Unfilled PPE resin. Lower odor during processing. Good for IC trays.
• PX5534: 30% glass fiber. High heat and low warpage. Works for water filters and water meters.
• NC208, NCF1010, NF1520: Wear resistant compounds. NC208 is electrically conductive. NCF1010 has glass, carbon fiber, and PTFE.
• HVN922: 10% glass reinforced with thin-wall moldability. CTI 2 rating.
• IGN320: 20% glass for high heat and high modulus. Used in automotive ignition coils.
• LPN130HG & LPN170HG: High gloss and low outgassing. Good for headlight reflectors.

Flame Retardant and Electrical Grades

These grades focus on safety and electrical performance.

• PX9406: Non-reinforced with non-halogenated FR. UL94 5VA at 2.5mm and V0 at 0.75mm. PFAS-free.
• PX9406K: Consumer electronics version. UL94 V0 at 1.5mm.
• PX9406P, PX9406PBIO5: PFAS-free for thin walls. PX9406PBIO5 is bio-based. Good for solar PV junction boxes.
• N802, N850: High flow and injection moldable. N850 carries UL94 5VA at 3mm. For electrical and business equipment.
• NH4030B, NH4050, NH5020: High flow and impact modified. NH4050 resists battery acid. Good for rail interiors and conduit.
• NH5110E & NH5120: NH5110E has low beard growth for extrusion. NH5120 works for outdoor enclosures.
• NH5120BIO1, NH5120BIO4: Bio-based with non-halogenated FR. Good for harsh outdoor environments.
• NH5120RC3: Contains 30% post-consumer recycled content. For HVAC components and solar boxes.
• NH6010B & NH6020: Non-reinforced and heat stabilized. NH6010B has low smoke and UL94 V0 at 1.5mm.
• HFM3015P, HM3020H, HM4025H: HFM3015P is 30% glass and mineral reinforced. Exceptional dimensional stability.
• HS2000X: 17% mineral filled. Strong electrical performance. Used in smoke detectors and pump housings.
• LS6010 & LTA6020: LTA6020 is impact modified and heat stabilized. UL94 5VA at 2.5mm.
• HMC1010 & HMC3008V: Electrically conductive. HMC1010 has 10% carbon fiber. HMC3008V has multiple reinforcements.
• HN731A & HN731SE: FDA and European food contact approved. HN731A is biocompatible. HN731SE offers chemical resistance.

Overview of Key Noryl Grade Families

This extensive portfolio allows engineers and designers to select materials precisely matched to their performance, processing, and regulatory requirements. For more detailed information or to source these grades, contact a NORYL resin supplier.
